The Square Plansifter used in grain, cereals and food processing plants in the grinding unit. Square Plansifter is providing a clean and orderly sorting of the milled product thanks to the different sizes of casing in each passage contained in the body and the body swinging with free movement.

GET AN OFFER

PRODUCT DESCRIPTION AND FEATURES

- The surfaces of the safes are covered with formica. Passage outer covers are insulated, thus preventing ingress of flour particles.

- Sieve outer body is mounted on hangers (flexible) on factory chassis

- Silk can be changed easily.

- Easy to maintain and install.

- Long life and Durable

- Low energy consumption

- High throughput capacity

- Quick and easy installation

- Low maintenance

- Hygienic working system

USAGE AREAS

  • Food processing industries
  • Flour mills
  • Semolina mills
  • Feed mills
  • Wheat, rye, oat, barley and corn processing facilities
  • Coffee and similar product processing facilities
  • Maize mills

WORKING SYSTEM

The product entrance is provided from the top of the screen. The product outlet is made from the bottom of the sieve. After being sieved and homogeneously separated, the product in various proportions is automatically channeled to the outlet duct through channels in the frame, channels between the frame and channels in the main frame and is discharged out of the outlet pipes with control pipes.

The product enters the first casing with one or two lots through the entrance on the top of the passage and flows through the passage height of all cases. By making a spacer between the frames of the main frames, the product output volume is prevented from accumulating and sufficient product flow is ensured. The telomes in each passage are compressed by means of jacks located on the outer surface of the screen.
